用途：Use
|
|
適合于橡膠粒、塑料粒、大米、小米、麥片、瓜子、奶粉、沖劑、調味品、種子、農藥等顆粒狀、粉狀物料的自動化包裝。
|
|
Suitable for automatic packaging particular, powder materials like rubber, plastic particular, grain, wheat, seeds, milk powder, medicine.
|
|
|
|
特點：Features
|
1.設計合理，結構簡潔。
2.單片機、步進電機控制，袋長設定方便，準確。
3.調速簡單、快捷。
4.選配裝置：色帶打碼機。
5.可選配八斗秤、大四斗秤、二斗秤。
|
Reasonable design, simple structure.
stepping motor, convenient and correct bag length setting.
Simple, fast speed regulation.
Optional: ribbon coding machine.
Big 4-bucket scale, small 4-bucket scale, 2-bucket scale can be
optional.
|
|
|
|
主要技術參數 Main Technical parameter
|
|
|
|
包裝速度
|
Packing speed
|
15-60bags/min
|
|
制袋尺寸
|
Bag-making size
|
(L)50-180mm (W)40-100mm
|
|
計量范圍
|
Filling range
|
5-200ml
|
|
包裝膜寬
|
Film width
|
100-220mm
|
|
包裝材料
|
Packing materials
|
OPP/CPP PET/PE 等復合材料
|
|
薄膜厚度
|
Film thickness
|
0.04-0.08mm
|
|
膜卷直徑
|
Film roll diameter
|
Max. 300mm
|
|
電源功率
|
Power supply
|
AC220V/380V 50Hz 1.5kw
|
|
機器尺寸
|
Machine dimensions
|
(L)800×(W)700×(H)1750mm
|
|
整機重量
|
Machine weight
|
300kg(約)
|
|
|
